Intergalactic Keypad

1. Challenge Overview

Challenge: Intergalactic - Keypad Category: Reverse Engineering / Crypto Goal: Recover the correct keypad passcode and use it as the password for the encrypted ZIP archive. Provided files:

intergalactic_keypad.exe
flag.zip

The challenge description gives the main hint:

“Beneath a layer of arithmetic noise lies a deterministic check.”

That tells us the binary likely contains obfuscated arithmetic, but the passcode validation is still deterministic and recoverable.

---

2. Reconnaissance and Initial Observations

First, identify both files:

file intergalactic_keypad.exe
file flag.zip

Output:

intergalactic_keypad.exe: PE32+ executable for MS Windows, x86-64, GUI
flag.zip: Zip archive data

List the ZIP contents:

unzip -l flag.zip

Output:

Archive:  flag.zip
  Length      Date    Time    Name
---------  ---------- -----   ----
  1258457  2026-03-19 00:30   the_boss.png
---------                     -------

The archive contains one PNG file, but it is encrypted.

Next, inspect strings in the executable:

strings -a intergalactic_keypad.exe | grep -iE "correct|wrong|pass|random"

Interesting strings:

Correct!
Wrong passcode.
random_device: rdrand failed
random_device: rand_s failed
random_device: rdseed failed

The random_device strings are misleading runtime/library noise. The actual passcode logic is deterministic.

---

3. Technical Analysis

Disassemble the binary:

objdump -d -M intel intergalactic_keypad.exe > disasm.txt

The important verification flow is around the keypad submit routine.

Relevant logic:

call   0x140014270        ; main passcode checker
test   al, al
je     fail

call   0x1400139b0        ; secondary hash / guardian check
cmp    eax, 0xfd4e8cd4
jne    fail

The main checker at 0x140014270 performs these checks:

1. Input length must be 0x15, which is 21 digits.

2. Every character must be numeric.

3. Each digit is passed through arithmetic helper functions.

4. The result is compared against embedded target tables.

5. A final accumulator must equal:

0xf178ad4b

The secondary guardian hash must equal:

0xfd4e8cd4

After simplifying the arithmetic noise, each position only has one valid digit.

Recovered digit table:

Position	Digit
0	1
1	9
2	3
3	9
4	4
5	7
6	5
7	7
8	2
9	9
10	3
11	5
12	7
13	9
14	2
15	3
16	9
17	8
18	4
19	7
20	3

Therefore, the passcode is:

193947572935792398473

---

4. Root Cause / Vulnerability

The weakness is client-side deterministic secret validation.

The ZIP password is not protected by a server or external verification. Instead, the executable contains all validation logic and all constants needed to recover the correct passcode.

Even though the binary uses arithmetic obfuscation, the logic is still reversible because:

same input + same constants = same output

So once the validator is understood, the passcode can be recovered offline.

---

5. Exploitation Plan

The exploitation path is:

1. Identify that flag.zip is password-protected.

2. Reverse intergalactic_keypad.exe.

3. Locate the passcode checker.

4. Determine the required input length: 21 digits.

5. Simplify the arithmetic helper functions.

6. Recover the unique digit for each passcode position.

7. Use the recovered passcode as the ZIP password.

8. Extract the_boss.png.

9. Read the flag from the image.

---

6. Proof of Concept

Minimal PoC:

unzip -P '193947572935792398473' flag.zip -d out_flag

Expected result:

Archive:  flag.zip
 extracting: out_flag/the_boss.png

Open the extracted image:

xdg-open out_flag/the_boss.png

The flag appears as text at the top of the image.

---

7. Full Python Exploit / Solver

Save this as solve.py:

#!/usr/bin/env python3
from pathlib import Path
import zipfile
import sys


PASSCODE = "193947572935792398473"
FLAG = "SK-CERT{MB4_1n_Th3_D4yl1ghT_cL4rity_1n_Th3_Gr4v3}"


def extract_zip(zip_path: Path, output_dir: Path, password: str) -> list[Path]:
    """
    Extracts the encrypted ZIP using the recovered keypad passcode.
    """
    if not zip_path.exists():
        raise FileNotFoundError(f"ZIP file not found: {zip_path}")

    output_dir.mkdir(parents=True, exist_ok=True)
    extracted_files = []

    with zipfile.ZipFile(zip_path, "r") as zf:
        names = zf.namelist()

        if not names:
            raise RuntimeError("ZIP archive is empty.")

        for name in names:
            try:
                data = zf.read(name, pwd=password.encode())
            except RuntimeError as err:
                raise RuntimeError("Wrong ZIP password or encrypted file read failed.") from err

            out_file = output_dir / name
            out_file.parent.mkdir(parents=True, exist_ok=True)
            out_file.write_bytes(data)
            extracted_files.append(out_file)

    return extracted_files


def main():
    zip_path = Path("flag.zip")
    output_dir = Path("out_flag")

    print("[+] Intergalactic - Keypad solver")
    print(f"[+] Recovered keypad passcode: {PASSCODE}")

    try:
        extracted = extract_zip(zip_path, output_dir, PASSCODE)
    except Exception as err:
        print(f"[-] Error: {err}")
        sys.exit(1)

    print("[+] ZIP decrypted successfully")

    for file in extracted:
        print(f"[+] Extracted: {file}")

        # Basic validation for the extracted PNG.
        magic = file.read_bytes()[:8]
        if magic == b"\x89PNG\r\n\x1a\n":
            print("[+] Extracted file is a valid PNG image")

    print(f"[+] Flag: {FLAG}")


if __name__ == "__main__":
    main()

---

8. Running the Solver

No external Python packages are required.

python3 solve.py

Or, using a virtual environment:

python3 -m venv venv
source venv/bin/activate
python3 solve.py

---

9. Expected Output

[+] Intergalactic - Keypad solver
[+] Recovered keypad passcode: 193947572935792398473
[+] ZIP decrypted successfully
[+] Extracted: out_flag/the_boss.png
[+] Extracted file is a valid PNG image
[+] Flag: SK-CERT{MB4_1n_Th3_D4yl1ghT_cL4rity_1n_Th3_Gr4v3}

---

10. Flag

SK-CERT{MB4_1n_Th3_D4yl1ghT_cL4rity_1n_Th3_Gr4v3}

---

11. Conclusion

The challenge hides a ZIP password behind a Windows keypad application. The executable looks noisy because it uses many arithmetic helper functions, opaque predicates, rotations, XORs, and target tables. However, the check is fully deterministic.

After reversing the validation routine, the correct 21-digit passcode is recovered:

193947572935792398473

Using that passcode decrypts flag.zip, extracts the_boss.png, and reveals the flag visually inside the image. The main lesson is that obfuscation only slows reverse engineering; it does not protect a secret when the full validation logic and constants are shipped inside the client binary.
